Implement-Side Triangle and Tractor Triangle
for easy coupling and uncoupling of front- und rear devices
The tractor linkage triangles of cat. I and II are made of high-strength steel and have a double guide roller and additional frame reinforcement. They are suitable for tools up to max. 1,500 kg weight* (center of gravity 1,000 mm of attachment). This also applies to the very stable tractor linkage triangles cat. III for very heavy use. The tractor linkage triangles cat. "communal" is ideal for all local municipal- and small tractors.
We offer the implement triangle according to ISO 11001-2 to pick up with the tractor triangle and to weld on the working equipment.
Tractor Linkage Triangle Category III
Weight: 55 kg
- steel, red RAL 3002
- acc. to ISO 11001-2,
category III - handle one-part
- total load
approx. 1,500 kg*
Tractor Linkage Triangle Category II S
Weight: 40 kg
- steel, red RAL 3002
- acc. to ISO 11001-2,
category II S - handle one-part
- total load
approx. 1,200 kg*
Tractor Linkage Triangle Category I
Weight: 33 kg
- steel, red RAL 3002
- acc. to ISO 11001-2,
category I - handle one-part
- total load
approx. 1,000 kg*
Tractor Linkage Triangle Cat. communal
Weight: 7 kg
- steel, red RAL 3002
- acc. to ISO 11001-2,
category communal - handle one-part
- total load
approx. 300 kg*
Implement Triangle Category I - III
Weight: 12 kg
- steel, primed
- optionally raw (uncoated)
- acc. to ISO 11001-2,
category I - III
Implement Triangle Category Communal
Weight: 4 kg
- steel, primed
- optionally raw (uncoated)
- acc. to ISO 11001-2,
category communal
