Data & Weights Series 248-2

Data & Weights Series 248-2

structure length (mm)		2,400 mm	2,700 mm	3,000 mm		snap-in tracks recessed	scuff rail increase 165 mm
structure length (mm)		body weight ( 2,550 mm width) approx. in kg with body inner heights				equipment, additional weight approx. ca. in kg
6,400		793	850	907		30	16
7,000		851	913	974		33	17
7,600		910	975	1,040		36	19
8,200		968	1,037	1,107		39	20
8,800		1,026	1,100	1,174		41	21
9,400		1,084	1,163	1,241		44	23
10,000		1,143	1,226	1,308		47	24
10,600		1,202	1,288	1,374		50	26
11,200		1,260	1,351	1,442		53	27
11,800		1,318	1,413	1,509		56	29
12,400		1,376	1,475	1,575		58	30
13,000		1,435	1,538	1,642		61	32
13,600		1,493	1,601	1,709		64	33

side door 950 x 2,000 mm 31 mm thick (ca. kg)***	2 rear doors (31 mm thick) ** for inner heights (ca. kg)			flap for tail-lift 31 mm thick (kg)	steel rear frame for inner height (ca. kg)
side door 950 x 2,000 mm 31 mm thick (ca. kg)***	2,400 mm	2,700 mm	3,000 mm	flap for tail-lift 31 mm thick (kg)	2,400 mm	2,700 mm	3,000 mm
36	96	105	121	29	32	36	40

* incl. lock & rain guard ** with 1 pair espagnolette locks

State 06/2022; subject to modifications and amendments

Other body lengths are available in 50 mm increments.
