The AluFoam panels are highly resistant to bending and are almost just as immune to strip damage as FerroFoam®, , but somewhat lighter. All foamed panels are significantly lighter and better insulating than conventional wall materials such as plywood. Moreover, they withstand the diffusion of vapour. The panels are usually coloured in RAL 9016.
| thickness (mm) | max. with (mm) | surface (layer | average weight kg/m² | heat transition coeffizient W/m² K | ||||
|---|---|---|---|---|---|---|---|---|
| outside (mm) | inside (mm) | |||||||
| 25 | 2.630 | 1.2 | 1.2 | 8.3 | 0.933 | |||
| 25 | 2.575 | 0.8 | 0.8 | 6.2 | 0.905 | |||
| 30 | 2.630 | 1.2 | 1.2 | 8.7 | 0.785 | |||
| 30 | 2.575 | 0.8 | 0.8 | 6.6 | 0.765 | |||
| 45 | 2.630 | 1.2 | 1.2 | 9.8 | 0.531 | |||
| 60 | 2.630 | 1.2 | 1.2 | 10.9 | 0.402 | |||
| 85 | 2.630 | 1.2 | 1.2 | 12.8 | 0.286 | |||
